500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System
  • 500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System
  • 500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System
  • 500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System
  • 500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System
  • 500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System

500X7B Dual-Color Reciprocating Spray Painting Machine with 7-Axis Servo Drive System

Product Details:
Place of Origin: China
Brand Name: ManSheng
Certification: CE, ISO 9001
Model Number: 500X7B
Detail Information
Place of Origin:
China
Brand Name:
ManSheng
Certification:
CE, ISO 9001
Model Number:
500X7B
Machine Body Material:
Stainless Steel, Aluminum, Steel
Machine Weight:
450KG
Spray Gun / Nozzle:
Mansheng Blue Gun 1.3
Machine Dimensions:
2232mm (Frame 1460mm) × 1500mm × 2231mm
Effective Stroke (XYZ):
900mm × 800mm × 350mm
Spraying Range:
700mm × 500mm
Spraying Method:
Dual-Gun Reciprocating, Reversible (2 Guns Independent Oil Output)
Drive Method:
7-Axis Precision Servo Drive
X Axis:
Horizontal (Left/Right)
Y Axis:
Vertical (Front/Back)
Z Axis:
Up/Down
A Axis:
Spray Gun Swing Angle
T1 Axis:
Station A Rotation
T2 Axis:
Station B Rotation
W Axis:
Chassis Rotation
Positioning Accuracy:
±0.2mm
Control System:
Mansheng Touch Screen Control System
Program Storage:
10000 Programs
Communication Port:
USB
Motor:
Xinje
Motion Module:
High-Precision Motion Module
Power Supply:
Hugong
Pneumatic Components:
Shannaisi, Airtac
Electrical Components:
CHNT, Delixi, Omron
Timing Belt Material:
Rubber
Control Buttons:
Tend
Machine Bearings:
NSK
Touch Screen:
Kunlun Tongtai
Rated Voltage:
220VAC/50Hz
Air Pressure:
0.6-0.8MPa
Exhaust Port:
Round / 400mm
Power Consumption:
4KW
Highlight:

High Light

Highlight:

7-Axis Precision Servo Drive

,

Dual Independent Spray Guns

,

±0.2mm Positioning Accuracy

Trading Information
Minimum Order Quantity:
1
Price:
12176
Packaging Details:
wooden box
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Product Description
500X7D Dual-Color Reciprocating Spray Painting Machine
The Mansheng 500X7B is a high-performance dual-color reciprocating spray painting machine engineered for precision industrial coating. Featuring a 7-axis servo drive system, dual independent spray guns with reversible spraying capability, and ±0.2mm positioning accuracy, it delivers consistent, uniform coating for a wide range of industrial manufacturing applications.
Key Features
  • 7-axis precision servo drive system (X, Y, Z, A, T1, T2, W) for multi-dimensional motion control
  • Dual-color reciprocating spraying with two independently controlled spray guns (Mansheng Blue Gun 1.3)
  • ±0.2mm high-precision positioning accuracy for uniform coating thickness
  • Reversible spraying with independent oil output per gun for complex workpieces
  • 10000-level program storage with USB communication for fast line changeovers
  • Mansheng touch screen control system with Kunlun Tongtai display
  • Effective stroke: 900mm * 800mm * 350mm (XYZ), spraying range: 700mm * 500mm
  • Robust construction with stainless steel, aluminum, and steel body (450KG)
  • Premium components: Xinje motor, NSK bearings, Omron electrical, Airtac pneumatics
  • Compact dimensions: 2232mm * 1500mm * 2231mm, rated at 220VAC/50Hz, 4KW
Technical Specifications
Parameter Specification
Model 500X7B Dual-Color Reciprocating Spray Painting Machine
Machine Body Material Stainless Steel, Aluminum, Steel
Weight 450KG
Spray Gun / Nozzle Mansheng Blue Gun 1.3
Machine Dimensions 2232mm (Frame 1460mm) * 1500mm * 2231mm
Effective Stroke (XYZ) 900mm * 800mm * 350mm
Spraying Range 700mm * 500mm
Spraying Method Dual-Gun Reciprocating, Reversible (2 Guns Independent Oil Output)
Drive Method 7-Axis Precision Servo Drive
Axis Configuration X (Horizontal), Y (Vertical), Z (Up/Down), A (Gun Swing), T1 (Station A), T2 (Station B), W (Chassis Rotation)
Positioning Accuracy ±0.2mm
Control System Mansheng Touch Screen Control System
Program Storage 10000 Programs
Communication Port USB
Motor Xinje
Motion Module High-Precision Motion Module
Power Supply Hugong
Pneumatic Components Shannaisi, Airtac
Electrical Components CHNT, Delixi, Omron
Timing Belt Material Rubber
Control Buttons Tend
Machine Bearings NSK
Touch Screen Kunlun Tongtai
Rated Voltage 220VAC/50Hz
Air Pressure 0.6-0.8MPa
Exhaust Port Round / 400mm
Power Consumption 4KW
Applications
Ideal for automated spray painting in various industrial sectors including automotive parts, metal enclosures, electronic housings, home appliance components, and general metal fabrication where precision dual-color coating is required.

Tags:

hardware spray painting machine,

metal parts coating equipment,

industrial metal coater
