| Place of Origin: | China |
| Brand Name: | ManSheng |
| Certification: | CE, ISO9001 |
| Model Number: | 600X5B |
The ManSheng 600X5B is a high-precision five-axis automatic spray painting machine engineered for industrial coating applications. Featuring dual 360° high-speed rotary spray guns with independent oil output control, ±0.2mm positioning accuracy, and a 600×600mm effective spray range, this machine delivers consistent, uniform coating results across diverse workpieces.
| Model | 600X5B |
| Body Material | Stainless Steel, Aluminum, Steel / Cold Plate (Optional) |
| Weight | 480KG |
| Overall Dimensions | 2508 (Rack 1440) × 1500 × 1910mm |
| Effective Travel (XYZ) | 600 × 900 × 260mm |
| Spray Range | 600 × 600mm |
| Spray Gun / Nozzle | ManSheng Blue Gun 1.3mm |
| Spray Method | 360° High-Speed Rotary + Reciprocating (2 Guns Independent) |
| Drive System | Five-Axis Precision Closed-Loop Stepper Drive |
| Positioning Accuracy | ±0.2MM |
| Control System | ManSheng Touch Screen Control Series |
| Program Storage | 10,000 Programs |
| Communication Port | USB |
| X Axis | Horizontal (Left-Right) |
| Y Axis | Vertical (Front-Back) |
| Z Axis | Up-Down |
| R Axis | Dual Spray Guns 360° High-Speed Rotation + Reciprocating |
| G Axis | Automatic Loading/Unloading Platform |
| Rated Voltage | 220VAC / 50HZ |
| Air Supply Pressure | 0.6 - 0.8MPA |
| Exhaust Port | Round / 400mm |
| Power Consumption | 0.95KW/H |
