Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control
  • Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control

Mansheng 600X5B 5-Axis Automatic Spray Painting Machine with Dual Gun Independent Control

Product Details:
Place of Origin: China
Brand Name: ManSheng
Certification: CE
Model Number: 600X5B
Detail Information
Place of Origin:
China
Brand Name:
ManSheng
Certification:
CE
Model Number:
600X5B
Body Material:
Stainless Steel, Aluminum, Steel / Cold Plate (Optional)
Weight:
480KG
Spray Gun / Nozzle:
Mansheng Blue Gun 1.3mm
Overall Dimensions:
2508 (Frame 1440) × 1500 × 1910mm
Effective Stroke (XYZ):
600 × 900 × 260mm
Spray Range:
600 × 600mm
Spray Method:
360° High-Speed Rotary + Reciprocating (Dual Gun Independent Output)
Drive Mode:
5-Axis Precision Closed-Loop Stepper Drive
X Axis:
Lateral (Left/Right)
Y Axis:
Vertical (Front/Back)
Z Axis:
Up/Down
R Axis:
Dual Gun 360° High-Speed Rotation + Reciprocating
G Axis:
Automatic Loading/Unloading Platform
Positioning Accuracy:
±0.2mm
Control System:
Mansheng Touch Screen Control Series
Program Storage:
10,000 Programs
Communication Port:
USB
Motor:
Leisai
Guide Rail:
HIWIN
Power Supply:
Hugong
Pneumatic Components:
Shannice / Airtac
Electrical Components:
CHINT / Delixi / Omron
Timing Belt Material:
Rubber
Control Buttons:
TEND
Bearings:
NSK
Touch Screen:
Kunlun Tongtai (MCGS)
Rated Voltage:
220VAC / 50Hz
Air Supply Pressure:
0.6-0.8 MPa
Exhaust Port Shape / Size:
Round / 400mm
Power Consumption:
0.95 KW/H
Highlight:

High Light

Highlight:

Dual Gun Independent Control

,

5-Axis Precision Drive

,

360° Rotary Spray Coating

Trading Information
Minimum Order Quantity:
1
Price:
USD14235
Packaging Details:
wooden box
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Product Description
Mansheng 600X5B 5-Axis Automatic Spray Painting Machine
The Mansheng 600X5B is a high-precision 5-axis automatic spray painting machine engineered for industrial coating applications. Featuring dual spray guns with independent fluid output control, 360° high-speed rotary spraying combined with reciprocating motion, this machine delivers exceptional coating uniformity across a 600*600mm spray range. Built with industrial-grade components including HIWIN guide rails, Leisai closed-loop stepper motors, and NSK bearings, it achieves ±0.2mm positioning accuracy for consistent, high-quality results.
Key Features
  • 5-Axis Precision Drive: X (lateral), Y (vertical), Z (up/down), R (dual gun 360° rotation + reciprocating), G (auto loading/unloading platform)
  • Dual Gun Independent Control: Two spray guns with independent fluid output for flexible, simultaneous operation
  • 360° High-Speed Rotary Spray: Combined rotary and reciprocating motion for comprehensive surface coverage
  • ±0.2mm Positioning Accuracy: Precision closed-loop stepper drive ensures repeatable, high-quality coating
  • Advanced Control System: Mansheng touch screen with 10,000-program storage, USB communication port
  • Industrial-Grade Components: HIWIN guides, Leisai motors, NSK bearings, Omron/CHINT/Delixi electrical components
  • Robust Construction: Stainless steel, aluminum, and steel body (cold plate optional) for long-term durability
  • Auto Platform: G-axis automatic loading/unloading for streamlined workflow
Technical Specifications
Model600X5B
Body MaterialStainless Steel, Aluminum, Steel / Cold Plate (Optional)
Weight480 KG
Spray Gun / NozzleMansheng Blue Gun 1.3mm
Overall Dimensions2508 (Frame 1440) * 1500 * 1910 mm
Effective Stroke (XYZ)600 * 900 * 260 mm
Spray Range600 * 600 mm
Spray Method360° High-Speed Rotary + Reciprocating (Dual Gun Independent Output)
Drive Mode5-Axis Precision Closed-Loop Stepper Drive
Positioning Accuracy±0.2 mm
Control SystemMansheng Touch Screen Control Series
Program Storage10,000 Programs
Communication PortUSB
MotorLeisai
Guide RailHIWIN
Power SupplyHugong
Pneumatic ComponentsShannice / Airtac
Electrical ComponentsCHINT / Delixi / Omron
Timing Belt MaterialRubber
Control ButtonsTEND
BearingsNSK
Touch ScreenKunlun Tongtai (MCGS)
Rated Voltage220 VAC / 50 Hz
Air Supply Pressure0.6 – 0.8 MPa
Exhaust Port Shape / SizeRound / 400 mm
Power Consumption0.95 KW/H
