Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating
  • Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating
  • Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating
  • Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating
  • Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating
  • Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating

Footwear Edge Automatic Spray Painting Equipment for Water Based Paint Coating

Product Details:
Place of Origin: Guangdong, China
Brand Name: Mansheng
Certification: ISO 9001:2015
Model Number: 500X7
Detail Information
Place of Origin:
Guangdong, China
Brand Name:
Mansheng
Certification:
ISO 9001:2015
Model Number:
500X7
Spray Method:
Automatic
Worktable Type:
Rotary Automatic Worktable
Nozzle Quantity:
1 Pc
Nozzle Movement:
Left-Right Reciprocating
Processing Size:
400 X 250 Mm
Heating Method:
Infrared Heating
Power Supply:
220V
Power:
5 KW
Air Pressure:
0.5 - 0.8 MPa
Rotation Speed:
150 - 500 R/min
Functions:
Dust Removal - Preheating - Spraying - Drying
Machine Dimensions:
1600 X 2620 X 2280 Mm
Machine Weight:
0.8 Ton
Color:
White
Highlight:

High Light

Highlight:

Automatic Shoe Edge Coater

,

500X7 Edge Spray Machine

,

Footwear Surface Painting Equipment

Trading Information
Minimum Order Quantity:
1
Price:
$12180
Packaging Details:
WOODEN BOX
Delivery Time:
15-25 working days after order confirmation
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
50 Sets per Month
Product Description
Shoe Edge Spray Coating Machine Automatic System for Footwear Sole Edge Surface Painting
500X7 Automatic Shoe Edge Spray Coating Machine

The 500X7 Shoe Edge Spray Coating Machine is a fully automatic precision spraying system designed for footwear sole edge and side surface coating. Equipped with an advanced rotary automatic worktable and infrared heating system, it delivers consistent, high-quality finishes for mass production environments.

Applicable Products
  • Shoe Soles
  • Shoe Edges
  • Sports Shoes / Sneakers
  • Shoe Buckles / Accessories
Key Product Features
  • Automatic Spraying: Fully automated left-right reciprocating spray gun with precision control for uniform coating coverage
  • High Efficiency & Energy Saving: Infrared heating system with integrated dust removal, preheating, spraying, and drying in one continuous workflow
  • Rotary Automatic Worktable: 360-degree rotating platform ensures complete edge coverage without manual repositioning
  • Wide Compatibility: Adjustable processing size up to 400 x 250mm, suitable for various shoe types and sizes
Working Process
Dust Removal → Preheating → Spraying → Drying — a complete 4-step automated cycle for efficient, repeatable results.
Technical Specifications
Parameter Specification
Model Shoe Sole Side Spray
Spray Method Automatic
Worktable Rotary Automatic Worktable
Nozzle Quantity 1 pc
Nozzle Movement Left-Right Reciprocating
Processing Size 400 x 250 mm
Heating Method Infrared Heating
Power Supply 220V
Power 5 kW
Air Pressure 0.5 - 0.8 MPa
Rotation Speed 150 - 500 r/min
Functions Dust Removal - Preheating - Spraying - Drying
Machine Dimensions 1600 x 2620 x 2280 mm
Machine Weight 0.8 ton
Color White
Packaging & Delivery
  • Packaging: Export-grade wooden box with moisture-proof lining
  • Delivery Time: 15-25 working days after order confirmation
  • Supply Capacity: 50 Sets per Month
