Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application
  • Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application

Shoe Heel Automatic Spray Painting Equipment for Water Based Paint Application

Product Details:
Place of Origin: Dongguan, China
Brand Name: Mansheng
Certification: ISO 9001:2015
Model Number: 500X8
Detail Information
Place of Origin:
Dongguan, China
Brand Name:
Mansheng
Certification:
ISO 9001:2015
Model Number:
500X8
Electrical Components:
Chint, Delixi, Omron
Communication Port:
USB
Pneumatic Parts:
Shannais, Airtac
Touch Screen:
Kunlun Tongtai
Control System:
Mansheng Touch Screen Control Series
Control Buttons:
Tend
Exhaust Port:
Round, 400mm
Motion Module:
High Precision Motion Module
Axes Layout:
X(L/R), Y(F/B), Z(U/D), R(Gun Rotation), A(Gun Angle Adjust), T1(Tray A), T2(Tray B), W(Tray Indexing)
Spray Method:
360 Degree Arbitrary Angle Tray Rotation + Reciprocating Spraying
Axis Control:
8-Axis Precision Servo Drive
Nozzle:
Mansheng Blue Gun, 1.3mm
Spraying Range:
500 X 400 X 350 Mm
Positioning Accuracy:
±0.2 Mm
Program Storage:
10000+ Programs
Motor:
Zinje
Power Supply:
220VAC/50Hz
Power:
4.5 KW/H
Air Pressure:
0.6 - 0.8 MPa
Machine Dimensions:
2143(Frame:1260) X 1500 X 2170 Mm
Machine Weight:
480 KG
Body Material:
Stainless Steel / Aluminum / Steel
Color:
White
Highlight:

High Light

Highlight:

500X8 Shoe Heel Spray Coater

,

8-Axis Precision Edge Machine

,

Heel Surface Painting Equipment

Trading Information
Minimum Order Quantity:
1
Price:
$12,765
Packaging Details:
WOODEN BOX
Delivery Time:
15-25 working days after order confirmation
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
50 Sets per Month
Product Description
Shoe Edge Spray Coating Machine 8-Axis Automatic System for Shoe Heel Surface Painting
500X8 Shoe Edge Spray Coating Machine for Heel Surface Painting

The 500X8 Shoe Edge Spray Coating Machine is an 8-axis precision servo-driven automatic spraying system designed for shoe heel surface coating. Featuring 360-degree arbitrary angle spraying with tray rotation and reciprocating motion, it delivers uniform coverage on heel surfaces with 10000+ program memory for efficient batch production.

Applicable Products
  • Shoe Heels
  • Stiletto Heels
  • Block Heels
  • Wedge Heels
  • Heel Components
Key Product Features
  • 8-Axis Precision Servo Drive: X, Y, Z, R (Gun Rotation), A (Gun Angle), T1/T2 (Tray Rotation), W (Tray Indexing) for complete multi-angle coverage
  • 360-Degree Arbitrary Angle Spraying: Tray rotation combined with reciprocating gun movement ensures uniform coating on all heel contours
  • 10000+ Program Memory: Store and instantly recall thousands of spraying programs for different heel styles, minimizing changeover time
  • High Precision: ±0.2mm positioning accuracy with high precision motion module for consistent, repeatable results
Working Process
Dust Removal → Preheating → 8-Axis Precision Spraying → Drying — advanced multi-axis automated cycle for efficient, high-quality heel coating.
Technical Specifications
Parameter Specification
Model 500X8 Heel Coating
Axis Control 8-Axis Precision Servo Drive
Spray Method 360 Degree Arbitrary Angle Spraying
Nozzle Mansheng Blue Gun, 1.3mm
Spraying Range 500 x 400 x 350 mm
Positioning Accuracy ±0.2 mm
Program Storage 10000+ Programs
Motor Zinje
Power Supply 220VAC/50Hz
Power 4.5 kW/H
Air Pressure 0.6 - 0.8 MPa
Control System Mansheng Touch Screen Control Series
Machine Dimensions 2143 x 1500 x 2170 mm
Machine Weight 480 KG
Body Material Stainless Steel / Aluminum / Steel
Color White
Packaging & Delivery
  • Packaging: Export-grade wooden box with moisture-proof lining
  • Delivery Time: 15-25 working days after order confirmation
  • Supply Capacity: 50 Sets per Month
