500X8 Eight Axis Precision Servo Reciprocating Spray Coating Machine for Plastic Components

Name: 500X8 Eight Axis Precision Servo Reciprocating Spray Coating Machine for Plastic Components
Brand: Dongguan Mansheng Automation Equipment Co., Ltd
SKU: 500X8
Price: 12765 USD
Availability: InStock

Product Details:

Brand Name:	ManSheng
Model Number:	500X8

Detail Information

Brand Name:

ManSheng

Model Number:

500X8

Body Material:

Stainless Steel, Aluminum, Steel

Weight:

480KG

Spray Gun / Nozzle:

Mansheng Blue Gun 1.3

Overall Dimensions:

2143 (Frame 1260) X 1500 X 2170mm

Spraying Range:

500 X 400 X 350mm

Spraying Method:

Material Tray 360 Rotation Any Angle + Reciprocating Spraying

Drive Method:

8-Axis Precision Servo Drive

X Axis:

Transverse (Left/Right)

Y Axis:

Vertical (Front/Back)

Z Axis:

Up/Down

R Axis:

Spray Gun Rotation

A Axis:

Spray Gun Swing Angle

T1 Axis:

A Material Tray Station Rotation

T2 Axis:

B Material Tray Station Rotation

W Axis:

Material Tray Revolution Position Change

Positioning Accuracy:

0.2MM

Control System:

Mansheng Touch Screen Control Series

Program Storage:

10000 Programs

Communication Port:

USB

Motor:

Xinje

Motion Module:

High-Precision Motion Module

Power Supply:

Hugong

Pneumatic Components:

Sunres, AirTAC

Electrical Components:

Chint, Delixi, Omron

Control Buttons:

Tiende

Touch Screen:

MCGS (Kunlun Tongtai)

Rated Voltage:

220VAC/50HZ

Air Supply Pressure:

0.6-0.8MPA

Exhaust Port:

Circular / 400mm

Power Consumption:

4.5KW/H

Highlight:

High Light

Highlight:

8-Axis Servo Precision Coating

Dual-Station High-Speed Production

0.2mm Uniform Surface Finish

Trading Information

Minimum Order Quantity:

Price:

USD12765

Packaging Details:

wooden box

Payment Terms:

L/C,D/A,D/P,T/T,Western Union

Product Description

500X8 Eight Axis Precision Servo Reciprocating Spray Coating Machine

Advanced eight-axis precision servo drive spray coating machine featuring 360 degree rotating material tray AB dual-station synchronous operation and high-speed reciprocating motion. Delivers uniform surface finishing for plastic components auto parts and motorcycle accessories with 0.2mm positioning accuracy and 2-3 times the productivity of conventional spraying equipment.

Core Advantages

8-Axis Precision Servo Drive: Supports complex arc and circular motion tracks. Material tray supports 360 forward reverse rotation; spray gun realizes 180 swing rotation. Highly simulates manual spraying to easily coat gaps and dead corners for uniform finish.
Heavy-Duty Precision Linear Modules: Different from low-cost optical-axis structures on the market. Higher load capacity and stable long-term continuous operation ideal for large heavy special-shaped workpieces.
AB Dual-Station Synchronous Operation: Load workpieces on Station A while spraying on Station B simultaneously eliminating idle waiting time and greatly boosting production efficiency.
High Positioning Accuracy for Flexible Production: 0.2mm accuracy 10000 spraying program storage. Easy touchscreen programming for quick switching between auto and motorcycle accessories. USB program import export for mass replication.
Tailored Spraying Solution for Auto and Motorcycle Accessories: Perfect for curved concave-convex irregular metal and plastic parts. Replaces manual operation for automatic mass production and stably reduces defective coating rate.

IndustryPoints Solved

Eliminates dead corners and gaps missing coating on irregular workpieces with 360 full rotation coverage
Ensures uniform film thickness and eliminates batch color differences caused by manual spraying
Complex arc and circular motion tracks simulate human spraying motion overcoming simple track limitations of conventional equipment
Heavy-duty precision linear modules outperform ordinary optical-axis modules with higher load capacity and stable long-term operation
AB dual-station design synchronizes loading/unloading with spraying eliminating single-station idle time
Built-in fully enclosed water curtain collects mist eliminating the high cost of dust-free workshop construction
180 spray gun swing rotation covers complex curved surfaces that ordinary fixed-angle guns cannot reach evenly
Automated mass production standardizes quality and significantly reduces manual labor costs

Technical Specifications

Specification	Details
Machine Model	500X8 High-Speed Reciprocating Machine
Body Material	Stainless Steel, Aluminum, Steel
Weight	480KG
Spray Gun / Nozzle Diameter	Mansheng Blue Gun 1.3
Overall Dimensions	2143 (Frame 1260) x 1500 x 2170mm
Spraying Range	500 x 400 x 350mm
Spraying Method	Material Tray 360 Rotation Any Angle + Reciprocating Spraying
Drive Method	8-Axis Precision Servo Drive
X Axis	Transverse (Left/Right)
Y Axis	Vertical (Front/Back)
Z Axis	Up/Down
R Axis	Spray Gun Rotation
A Axis	Spray Gun Swing Angle
T1 Axis	A Material Tray Station Rotation
T2 Axis	B Material Tray Station Rotation
W Axis	Material Tray Revolution Position Change
Positioning Accuracy	0.2MM
Control System	Mansheng Touch Screen Control Series
Program Storage	10000 Programs
Communication Port	USB
Motor	Xinje
Motion Module	High-Precision Motion Module
Power Supply	Hugong
Pneumatic Components	Sunres, AirTAC
Electrical Components	Chint, Delixi, Omron
Control Buttons	Tiende
Touch Screen	MCGS (Kunlun Tongtai)
Rated Voltage	220VAC/50HZ
Air Supply Pressure	0.6-0.8MPA
Exhaust Port Shape / Size	Circular / 400mm
Power Consumption	4.5KW/H

Applications

Ideal for plastic components auto spare parts small plastic interior fittings fasteners tiny auto metal parts vehicle plastic decorations small motorcycle accessories miniature plastic parts clasps small metal decorative components compact casings small plastic products miniature hardware buttons tiny irregular workpieces mini 3C shells and small wooden pieces. Delivers 2-3 times the output of traditional reciprocating machines with fully automated high-precision mass production capability.
