500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine

Product Details:

Brand Name:	ManSheng
Certification:	CE

Detail Information

Brand Name:

ManSheng

Certification:

Body Material:

Stainless Steel, Aluminum, Steel

Weight:

480KG

Spray Gun:

ManSheng Blue Gun 1.3mm

Machine Dimensions:

2143x1500x2170mm

Spraying Area:

500x400x350mm

Spraying Mode:

360° Tray Rotation + Reciprocating

Drive Mode:

8-Axis Precision Servo

Axis Configuration:

X,Y,Z,R,A,T1,T2,W

Positioning Accuracy:

±0.2mm

Control System:

ManSheng Touch Screen

Program Storage:

10000 Programs

Motor:

Xinje

Motion Module:

High-Precision Motion Module

Power Supply:

Hugong

Pneumatic Components:

SNS, AirTAC

Electrical Components:

CHINT, Delixi, Omron

Control Button:

TEND

Touch Screen:

Kunlun Tongtai

Rated Voltage:

220VAC/50Hz

Air Pressure:

0.6-0.8MPa

Exhaust Port:

Round 400mm

Power Consumption:

4.5KW/H

Highlight:

High Light

Highlight:

High-Speed Reciprocating Spray Machine

8-Axis Servo Painting Robot

Automatic Industrial Spray Coating Equipment

Trading Information

Minimum Order Quantity:

Price:

USD12765

Packaging Details:

wooden box

Payment Terms:

L/C,D/A,D/P,T/T,Western Union

Product Description

500X8 8-Axis High-Speed Reciprocating Automatic Spray Painting Machine

The 500X8 is a heavy-duty 8-axis high-speed reciprocating automatic spray painting machine, engineered for large-scale industrial surface coating applications. Featuring an advanced servo drive system with 360-degree tray rotation, it delivers exceptional throughput with ±0.2mm positioning accuracy. The robust 480KG construction ensures stability and durability for continuous production environments.

Key Highlights

Drive System

8-Axis Precision Servo

Accuracy

±0.2mm

Spray Gun

ManSheng Blue Gun 1.3mm

Spraying Mode

360° Tray + Reciprocating

Program Storage

10,000 Programs

Spraying Area

500 * 400 * 350mm

Technical Specifications

Parameter	Specification
Model	500X8
Body Material	Stainless Steel, Aluminum, Steel
Weight	480KG
Machine Dimensions	2143 * 1500 * 2170mm
Spraying Area	500 * 400 * 350mm
Positioning Accuracy	±0.2mm
Axis Configuration	X, Y, Z, R, A, T1, T2, W (8-Axis)
Rated Voltage	220VAC / 50Hz
Air Pressure	0.6-0.8MPa
Power Consumption	4.5KW/H
Exhaust Port	Round / 400mm

Premium Components

Component	Brand / Spec
Motor	Xinje
Motion Module	High-Precision Motion Module
Pneumatic Components	SNS, AirTAC
Electrical Components	CHINT, Delixi, Omron
Power Supply	Hugong
Touch Screen	Kunlun Tongtai
Control Button	TEND
