Automatic Spray Coating Machine | High-precision Spraying for Perfume Bottle Casings
The Man Sheng Automatic Spray Coating Machine is a high-precision automatic spray coating system engineered for perfume bottle casing surface treatment. Featuring 360-degree high-speed rotary spraying and dual independent WA101 spray guns, this coating machine delivers uniform, high-quality coating on perfume bottle casings, fragrance packaging, and decorative glass components.
Core Specifications
| Parameter |
Specification |
| Model |
Automatic Spray Coating Machine |
| Body Material |
Stainless Steel, Aluminum, Steel |
| Weight |
210KG |
| Overall Dimensions |
845 x 740 x 1580mm (Frame 715mm) |
| Effective Stroke |
400 x 400 x 120mm |
| Spraying Range |
400 x 400mm |
| Spray Gun / Nozzle |
WA101 Spray Gun 0.5mm |
| Positioning Accuracy |
0.05mm |
Advanced Glass Bottle Spraying System
The system features dual WA101 spray guns (0.5mm nozzle) with independent oil output control, enabling simultaneous multi-angle coating of perfume bottle casings. The 360-degree rotation combined with reciprocating spray motion ensures complete and uniform coverage across curved surfaces, including casing contours, cap threads, and decorative embossing.
| Parameter |
Specification |
| Spraying Mode |
360 Degree Rotation + Reciprocating Spraying (2 Guns, Independent Oil Output) |
| Driving Mode |
Closed-Loop Stepper Drive |
Precision Motion System
The system is equipped with a closed-loop stepper drive system featuring Leadshine motors, HIWIN linear guides, and NSK bearings. The axes configuration includes X (Left/Right), Y (Front/Back), Z (Up/Down), U (Gun 360 Degree Rotation), V (Station A Rotation), and W (Station B Rotation), delivering 0.05mm positioning accuracy essential for perfume bottle casing finishing.
Control System
| Parameter |
Specification |
| Control System |
Touch Screen |
| Program Storage |
10,000+ Programs |
| Communication Port |
USB |
The intuitive touch screen interface allows operators to store up to 10,000 coating programs for different bottle shapes, sizes, and coating specifications. USB data port enables easy program transfer and backup.
Premium Components
| Component |
Brand / Specification |
| Motor |
Leadshine |
| Linear Guide |
HIWIN |
| Bearing |
NSK |
| Spray Gun |
WA101 0.5mm |
Power and Operating Requirements
| Parameter |
Specification |
| Rated Voltage |
220VAC / 50Hz |
| Air Supply Pressure |
0.4 - 0.6MPa |
| Exhaust Port |
Round / 200mm |
| Power Consumption |
0.55KW/H |
Perfume Bottle Casing Applications
- Perfume bottle casings and outer shells
- Fragrance and cologne packaging
- Cosmetic compact and lipstick casings
- Serum and essential oil bottle casings
- Decorative casings with embossing
- Frosted and matte finish casings
- UV-curable and metallic coating finishes
This system handles primers, base coats, metallic finishes, UV-curable coatings, and protective clear coats for premium fragrance packaging.
The Man Sheng Automatic Spray Coating Machine delivers high-precision, energy-efficient coating for the fragrance packaging industry. With its compact footprint, dual-station design, and industrial-grade components, this coating machine is the ideal solution for manufacturers seeking consistent, high-quality perfume bottle casing finishing. Contact us today to discuss your perfume bottle casing coating requirements.
