500X7A Automatic Spray Painting Machine - 360 Degree Rotary Spraying Helmet Brim Surface Coating

Product Details:

Detail Information

Frame Material:

Stainless Steel, Aluminum, Steel

Weight:

450KG

Spray Gun:

Mansheng Blue Gun 1.3

Overall Dimensions:

2450 X 1500 X 2100mm

Effective Stroke:

520 X 670 X 260mm

Spraying Range:

500mm X 500mm

Spraying Method:

360° Rotary + Reciprocating

Drive System:

7-Axis Closed-Loop Stepper

Axes Configuration:

X, Y, Z, R, T1, T2, W

Positioning Accuracy:

±0.05mm

Control System:

Mansheng Touch Screen

Program Storage:

10000 Programs

Communication Port:

USB

Motors:

Leadshine

Guide Rails:

HIWIN

Power Supply:

Hugong

Pneumatic Components:

SNS, AirTAC

Electrical Components:

Chint, Delixi, Omron

Timing Belt Material:

Rubber

Control Buttons:

Tend

Bearings:

NSK

Touch Screen:

Kunlun Tongtai

Rated Voltage:

220VAC/50HZ

Air Supply Pressure:

0.6-0.8MPA

Exhaust Port:

Round, 400mm

Power Consumption:

0.95KW/H

Application:

Helmet Brim Surface Coating

Highlight:

High Light

Highlight:

7-Axis Closed-Loop Stepper Drive

360 Degree Rotary Spraying

0.05mm Positioning Accuracy

Trading Information

Minimum Order Quantity:

Price:

USD12176

Packaging Details:

wooden box

Payment Terms:

L/C,D/A,D/P,T/T

Product Description

500X7A Automatic Spray Painting Machine for Helmet Brim Surface Coating

The 500X7A automatic spray painting machine is a 7-axis precision closed-loop stepper driven finishing line engineered for helmet brim surface coating. Featuring 360-degree high-speed rotary spraying combined with reciprocating spraying, dual guns with independent oil output and ±0.05mm positioning accuracy, it delivers precise, consistent and efficient coating results for industrial manufacturing environments.

7-axis precision closed-loop stepper drive (X, Y, Z, R, T1, T2, W)
360-degree high-speed rotary spraying plus reciprocating spraying
Dual spray guns with independent oil output (Mansheng blue gun, 1.3 nozzle)
±0.05mm positioning accuracy covering 500mm x 500mm spraying range
HIWIN guide rails with Leadshine motors
Mansheng touch screen control system storing up to 10,000 programs
Stainless steel, aluminum and steel frame construction

Technical Specifications

Model	500X7A Hinge Mold Automatic Spray Painting Machine
Frame Material	Stainless Steel, Aluminum, Steel
Weight	450KG
Spray Gun / Nozzle	Mansheng Blue Gun 1.3
Overall Dimensions	2450 (Frame 1460) mm x 1500mm x 2100mm
Effective Stroke	520mm x 670mm x 260mm
Spraying Range	500mm x 500mm
Spraying Method	360-Degree High-Speed Rotary Spraying + Reciprocating Spraying (2 Guns with Independent Oil Output)
Drive System	7-Axis Precision Closed-Loop Stepper Drive
X-Axis	Horizontal (Left/Right)
Y-Axis	Vertical (Front/Back)
Z-Axis	Up/Down
R-Axis	Dual Spray Guns 360-Degree High-Speed Rotation + Reciprocating
T1-Axis	Station A Rotation
T2-Axis	Station B Rotation
W-Axis	Chassis Rotation
Positioning Accuracy	±0.05MM
Control System	Mansheng Touch Screen Control System
Program Storage	10,000 Programs
Communication Port	USB
Motors	Leadshine
Guide Rails	HIWIN
Power Supply	Hugong
Pneumatic Components	SNS, AirTAC
Electrical Components	Chint, Delixi, Omron
Timing Belt Material	Rubber
Control Buttons	Tend
Bearings	NSK
Touch Screen	Kunlun Tongtai
Rated Voltage	220VAC/50HZ
Air Supply Pressure	0.6-0.8MPA
Exhaust Port Shape / Size	Round / 400mm
Power Consumption	0.95KW/H
