Automated Spray Coating Line for Leather Goods
The Man Sheng 600X5 Automated Spray Coating Line is a compact precision coating system engineered for leather goods surface treatment. Featuring 360-degree high-speed rotary spraying with dual independent WA101 spray guns (0.5mm nozzle), this line delivers uniform, high-quality coating on leather handbags, belts, wallets, leather straps, and leather trims. With a positioning accuracy of 0.05mm and a space-saving 845x740mm footprint, this machine integrates seamlessly into leather goods finishing production lines.
Core Specifications
| Parameter |
Specification |
| Model |
600X5 Automated Spray Coating Line |
| Application |
Leather Surface Coating |
| Body Material |
Stainless Steel, Aluminum, Steel |
| Weight |
210KG |
| Overall Dimensions |
845 x 740 x 1580mm (Frame 715mm) |
| Effective Stroke |
400 x 400 x 120mm |
| Spraying Range |
400 x 400mm |
| Spray Gun / Nozzle |
WA101 Spray Gun 0.5mm |
| Positioning Accuracy |
0.05mm |
Advanced Leather Goods Spraying System
The system features dual WA101 spray guns (0.5mm nozzle) with independent oil output control, enabling simultaneous multi-angle coating of leather goods. The 360-degree rotation combined with reciprocating spray motion ensures complete and uniform coverage across curved and contoured leather surfaces, including handbag edges, belt straps, wallet panels, and embossed leather trims. This system handles primers, base coats, color finishes, textured effects, and protective clear coats for premium leather finishing.
| Parameter |
Specification |
| Spraying Mode |
360 Degree Rotation + Reciprocating Spraying (2 Guns, Independent Oil Output) |
| Driving Mode |
Closed-Loop Stepper Drive |
Precision Motion System
Equipped with a closed-loop stepper drive system featuring Leadshine motors, HIWIN linear guides, and NSK bearings. The multi-axis configuration delivers 0.05mm positioning accuracy essential for precision leather surface finishing, ensuring consistent coating thickness across all leather goods profiles including flat panels, rolled edges, straps, and curved bag bodies.
Control System
| Parameter |
Specification |
| Control System |
Touch Screen |
| Program Storage |
10,000+ Programs |
| Communication Port |
USB |
The intuitive touch screen interface allows operators to store up to 10,000 coating programs for different leather product sizes, shapes, and coating specifications. USB data port enables easy program transfer and backup.
Premium Components
| Component |
Brand / Specification |
| Motor |
Leadshine |
| Linear Guide |
HIWIN |
| Bearing |
NSK |
| Spray Gun |
WA101 0.5mm |
Power and Operating Requirements
| Parameter |
Specification |
| Rated Voltage |
220VAC / 50Hz |
| Air Supply Pressure |
0.4 - 0.6MPa |
| Exhaust Port |
Round / 200mm |
| Power Consumption |
0.55KW/H |
Leather Goods Coating Applications
- Leather handbags and bag bodies exterior coating
- Leather belts and strap edge finishing
- Wallets, card holders, and small leather goods
- Leather shoe uppers and leather trims
- Embossed and textured leather pattern coating
- Matte, glossy, and metallic leather finish application
- Primer, color coat, and protective clear coat applications
The Man Sheng 600X5 Automated Spray Coating Line delivers high-precision, energy-efficient coating for the leather goods manufacturing industry. With its compact footprint, dual-station design, and industrial-grade components, this line is the ideal solution for manufacturers seeking consistent, high-quality leather finishing.
Contact us today to discuss your leather goods coating requirements.
