Shoe Sole Automatic Spray Painting Machine for Water Based Paint Coating
  • Shoe Sole Automatic Spray Painting Machine for Water Based Paint Coating
  • Shoe Sole Automatic Spray Painting Machine for Water Based Paint Coating
  • Shoe Sole Automatic Spray Painting Machine for Water Based Paint Coating
  • Shoe Sole Automatic Spray Painting Machine for Water Based Paint Coating

Shoe Sole Automatic Spray Painting Machine for Water Based Paint Coating

Product Details:
Place of Origin: Dongguan, China
Brand Name: Mansheng
Certification: ISO 9001:2015
Model Number: 250X9
Detail Information
Place of Origin:
Dongguan, China
Brand Name:
Mansheng
Certification:
ISO 9001:2015
Model Number:
250X9
Body Material:
Stainless Steel / Aluminum / Steel
Weight:
400KG
Spray Gun & Nozzle:
Mansheng Blue Gun, 1.3mm
Overall Dimension:
1726(Frame:1050)mm × 1200mm × 1868mm
Spraying Range:
250mm × 250mm
Spraying Mode:
Dual-Station Reciprocating Spraying
Drive Mode:
9-Axis Precision Closed-Loop Stepper Drive
Axes Function:
X(L/R), Y(F/B), Z(U/D), A(Dual Gun Angle), T1(Station A Rotate), T2(Station B Rotate), I1(Station A Tilt), I2(Station B Tilt), W(Base Rotate)
Positioning Accuracy:
±0.2mm
Control System:
Mansheng Touch Screen Control Series
Program Storage:
10,000+ Programs
Communication Port:
USB
Motor:
Leadshine
Linear Guide:
HIWIN
Power Supply:
Hugong
Pneumatic Parts:
Shannais, Airtac
Electrical Components:
Chint, Delixi, Omron
Timing Belt Material:
Rubber
Control Buttons:
Tend
Bearings:
NSK
Touch Screen:
Kunlun Tongtai
Rated Voltage:
220VAC/50Hz
Air Supply Pressure:
0.4-0.6MPa
Exhaust Port:
Round / 310mm
Power Consumption:
0.75KW/H
Highlight:

High Light

Highlight:

9-Axis Dual-Station Sole Coating Machine

,

High-Speed Footwear Sole Spray Equipment

,

Dual-Station Shoe Sole Painting System

Trading Information
Minimum Order Quantity:
1
Price:
$14,235
Packaging Details:
WOODEN BOX
Delivery Time:
15-25 working days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
50 Sets per Month
Product Description
Dual-Station High-Speed Reciprocating Spray Painting Machine for Shoe Sole Surface Coating Finishing
Product Overview

The Mansheng 9-Axis Dual-Station High-Speed Reciprocating Spray Painting Machine is a compact yet powerful automatic coating system engineered for precision shoe sole surface spraying and finishing. Featuring an advanced 9-axis closed-loop stepper drive system with Leadshine motors and HIWIN linear guides, this dual-station machine delivers exceptional coating uniformity, high throughput, and energy efficiency for footwear sole manufacturing.

Its dual independent workstations enable continuous loading and spraying, maximizing production output while maintaining consistent ±0.2mm coating accuracy across all sole types.

Key Features
  • 9-Axis Precision Closed-Loop Stepper Drive - Full control over X, Y, Z, A, T1, T2, I1, I2, W axes with Leadshine motors for precise motion control on complex sole geometries
  • Dual-Station Reciprocating Spraying - Two independent workstations with tilt control (I1, I2) enable continuous production, with one station loading while the other sprays for maximum throughput
  • HIWIN Linear Guides & NSK Bearings - Premium motion components ensure smooth, vibration-free operation and long-term reliability in demanding production environments
  • ±0.2mm Positioning Accuracy - Closed-loop stepper drive eliminates step loss, ensuring consistent coating thickness and quality batch after batch
  • 10,000+ Program Storage - Store and recall complex spraying programs via USB port for quick changeover between different sole models, sizes, and coating specifications
  • Mansheng Touch Screen Control - User-friendly interface with Kunlun Tongtai display for easy parameter adjustment and real-time operation monitoring
  • Compact Footprint & Energy Efficient - 1726mm * 1200mm * 1868mm compact frame with only 0.75KW/H power consumption, ideal for space-constrained production lines
Technical Specifications
Parameter Specification
Model 250X9B Dual-Station High-Speed Reciprocating Spray Machine
Body Material Stainless Steel / Aluminum / Steel
Weight 400KG
Spray Gun & Nozzle Mansheng Blue Gun, 1.3mm
Overall Dimension 1726(Frame:1050)mm * 1200mm * 1868mm
Spraying Range 250mm * 250mm
Spraying Mode Dual-Station Reciprocating Spraying
Drive Mode 9-Axis Precision Closed-Loop Stepper Drive
Axes Function X(L/R), Y(F/B), Z(U/D), A(Dual Gun Angle), T1(Station A Rotate), T2(Station B Rotate), I1(Station A Tilt), I2(Station B Tilt), W(Base Rotate)
Positioning Accuracy ±0.2mm
Control System Mansheng Touch Screen Control Series
Program Storage 10,000+ Programs
Communication Port USB
Rated Voltage 220VAC/50Hz
Air Supply Pressure 0.4-0.6MPa
Exhaust Port Round / 310mm
Power Consumption 0.75KW/H
Premium Components
  • Motor: Leadshine
  • Linear Guide: HIWIN
  • Bearings: NSK
  • Power Supply: Hugong
  • Pneumatic Parts: Shannais, Airtac
  • Electrical Components: Chint, Delixi, Omron
  • Timing Belt: Rubber
  • Control Buttons: Tend
  • Touch Screen: Kunlun Tongtai
Shoe Sole Coating Applications
  • Rubber outsoles and sneaker soles
  • EVA foam and PU midsole surface coating
  • TPU sole edge and contour finishing
  • Athletic and sports shoe sole spraying
  • Casual and fashion footwear sole coating
  • Work boot and safety shoe sole finishing
  • Anti-slip and grip-pattern coating applications
  • Primer, base coat, color coat, and clear coat finishing

The Mansheng 9-Axis Dual-Station Spray Painting Machine delivers high-precision, energy-efficient coating in a compact footprint ideal for footwear sole manufacturers. With its dual-station continuous production design, premium Leadshine/HIWIN/NSK motion components, and only 0.75KW/H power consumption, this machine combines efficiency and precision for consistent, high-quality shoe sole surface finishing.

Contact us today to discuss your footwear sole coating requirements.

Tags:

shoe sole spray machine,

footwear coating equipment,

sole painting machine
